Side Bend Single-White 24V
List Price
$38.30
Stock
In stock
Only %1 left
Part
LN1S1W24
List Price
Description
Side Bend Neon Flexible Lighting achieves a seamless lighting effect for recessed applications such as closets, in architectural accents, or in curved artistic installations. Silicone housing is flexible and protects the diodes from moisture, dust, and damage. Recommended ¾" thick panel for recess mounting applications. Optional metal mounting clip for surface mount applications allows lighting to be mounted with the light facing away from the installation surface or for the light to run parallel to the installation surface. Both ends of the lighting have wire leads to allow 2 segments to be cut to length; not reconnectable in the field. 24-volt. Contact Design Services for FREE layout and technical support at 866-848-9094.
More Information
| FEATURES |
|---|
| Field cuttable approximately every 1.3125" for versatile installation |
| Flexible silicone housing achieves the "dot-free" look of a frosted lens while retaining the flexibility of tape lighting |
| Low profile—just 4 mm wide x 9 mm tall |
| IP66 waterproof rated |
| Dimmable with compatible dimmer and smart-home compatible with WAV smart home control |
| 90+ CRI for true rather than faded colors |
| 50,000 hour LED life at 70% lumen maintenance means long-lasting illumination |
| NOTES |
|---|
Details
| Item Number | LN1S1W24 |
|---|---|
| ADA | No |
| Packaging Type | Small Package |
| Brand | Task Lighting |
| Finish | White |
| Width | 5.2 mm |
| Beam Angle | 120° |
| CRI | 90+ |
| Dimmable | Dimmable with compatible dimmer or dimming system |
| Bend Diameter | Side Bend R>1-3/16" (R>30 mm) |
| Certification | UL, CE, RoHs |
| Installation | Surface, Recessed |
| IP Rating | IP66 |
| Light Output | High |
| Operating Temperature | -4°F to 140°F (-20°C to 60°C) |
| Recessed Depth | 9 mm |
| Watts per Foot | 3.1 |
Resources
| Specifications |
| Installation Instructions |
| Warranty |
